Four strategically positioned pivot points and two linkages work together to create a single floating pivot point for the most active, efficient suspension system.
Sale 40%
{{ productAwardLocalized.Quote }}
This superlight carbon composite XC flyer blends the most up-to-date Maestro suspension technology with the speed, control and stability of progressive 29er geometry. If XC racing is your game, this is your express route to the podium.
Engineered with a superlight Advanced-grade carbon frame (including the front triangle and rear swingarm) this full-suspension 29er features 90mm of smooth rear suspension travel and 100mm up front. The proven Maestro rear suspension system includes a trunnion mount shock with a lower leverage ratio for efficient pedalling and braking performance. The linkage allows for shorter chainstays which improves the bike’s climbing capabilities and overall agility. The Advanced Forged Carbon Composite upper rocker arm is lighter, stiffer and stronger than the previous aluminium version. Other updates include wider Boost hub spacing and an integrated Giant WheelSystem that gives you super strong and stiff wheels for confident, precise handling on XC terrain.
Key Performance Factors
XC Efficiency
The Advanced Carbon Composite frameset (mainframe and rear swingarm) is superlight with aggressive 69-degree head tube and 73.5-degree seat tube angles for faster climbing and accelerating.
29er speed and stability
Frame geometry and suspension are optimised for 29-inch wheels to deliver a race-winning combo of speed and stability on XC terrain.
Traction and control
Updated Maestro Suspension with an Advanced Forged Carbon Composite rocker arm and trunnion-mount shock delivers smooth suspension performance on XC climbs, corners and descents.
Highlights
Engineered with a superlight Advanced-grade carbon frame, including the front triangle and rear swingarm, this full-suspension 29er features 90mm of smooth rear suspension travel and 100mm up front. The proven Maestro rear suspension system includes a trunnion mount shock with a lower leverage ratio for efficient pedaling and braking performance. The linkage allows for shorter chainstays, which improves the bike’s climbing capabilities and overall agility. The Advanced Forged Composite upper rocker arm is lighter, stiffer and stronger than the previous aluminum version, and other updates include wider Boost hub spacing and an integrated Giant WheelSystem that gives you super strong and stiff wheels for confident, precise handling on XC terrain.
Geometry
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 39015.4 | 44017.3 | 49019.3 | 53521.1 |
| B | Seat Tube Angle (degrees) | 73.5° | 73.5° | 73.5° | 73.5° |
| C | Top Tube Length (mm) (inch) | 59023.2 | 61024 | 63024.8 | 65025.6 |
| D | Head Tube Length (mm) (inch) | 953.7 | 953.7 | 1054.1 | 1154.5 |
| E | Head Tube Angle (degrees) | 69.0° | 69.0° | 69.0° | 69.0° |
| F | Fork Rake (mm) (inch) | 512 | 512 | 512 | 512 |
| G | Trail (mm) (inch) | 88.93.5 | 88.93.5 | 893.5 | 893.5 |
| H | Wheelbase (mm) (inch) | 111343.8 | 113344.6 | 115445.4 | 117546.3 |
| I | Chain Stay Length (mm) (inch) | 43817.2 | 43817.2 | 43817.2 | 43817.2 |
| J | Bottom Bracket Drop (mm) (inch) | 451.8 | 451.8 | 451.8 | 451.8 |
| K | Stack (mm) (inch) | 58523 | 58523 | 59423.4 | 60423.8 |
| L | Reach (mm) (inch) | 41716.4 | 43717.2 | 45417.9 | 47118.5 |
| M | Stand Over Height (mm) (inch) | 74729.4 | 78030.7 | 81732.2 | 84333.2 |
| N | Handlebar Width (mm) (inch) | 78030.7 | 78030.7 | 78030.7 | 78030.7 |
| O | Stem Length (mm) (inch) | 602.4 | 702.8 | 803.1 | 903.5 |
| P | Crank Length (mm) (inch) | 1706.7 | 1756.9 | 1756.9 | 1756.9 |
| Q | Wheel Size | 29" | 29" | 29" | 29" |
Techs & Features
Advanced Composite Technology
Giant’s High Performance Grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of these framesets is assembled and molded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.
Advanced Forged Composite Technology
A state-of-the-art high-pressure moulding process is used to produce complex-shaped carbon fibre components that are lighter, stiffer and stronger than similar components made from aluminium. This technology is used in critical performance parts such as Maestro Suspension rocker links.
Maestro Suspension Technology
Four strategically positioned pivot points and two linkages all work together to create a single floating pivot for the most active, efficient and independent suspension system on the trail.
OverDrive
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
Tubeless System
Fewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.
